category 03

ceiling systems

Lift your brand overhead. Premium ceiling systems with 12 m span, 6 m height, 43 kg/m² load capacity.

products in this category

octarig
Modular overhead system for tall exhibition installations. DIN 4102 Class B1, 5-year warranty.
Span between hinges: up to 12 m (6 m + 6 m)
Pylon cantilever: 3 m (3000 mm) past the rear hinge
Maximum height (floor posts): 6000 mm
Main beam: R 102, 240 x 80 mm
Load capacity: 43 kg/m (12 m span, R 290 connection)
Material: Aluminium + steel accessories
Fabric tensioning: clips M 1325 (horizontal / vertical)
Fire protection certificate: DIN 4102, Part 1, Class B1 (system); Part 4, 2.21 g (aluminium)
Warranty: 5 years on Octa aluminium profiles, 2 years on LED lights
details

Need a quote or technical specifications for this category?
