octalux led systems for trade fairs
- Lighting type
- COB LED diodes (chip-on-board)
- Colours
- Warm white, cool white or RGB (16.8 million colour shades)
- Control
- Remote control (colour and brightness adjustment from outside)
- Dimming
- Yes (from dimmed to bright)
Glowing edges
octalux combines clean design with a striking visual impact. The modular profile system with integrated LED technology brings glowing edges, seamless transitions and maximum design freedom to every project. At the push of a button, 16.8 million colors unleash their full potential for brand presentations that stand out. Ideal for trade fairs, retail, interior design and everything in between.
Compact light profiles
Compact light profiles that create targeted accents. With a glowing surface and the full RGB color spectrum, even the smallest exhibition space can be transformed. Profile depth: 40 mm. Illumination: 1 surface. Application: retail, fair spaces, events. Compatible with: maxima 40, octawall 40, octaclassic.
Illuminated profiles with up to three glowing sides
Illuminated profiles with up to three glowing sides in RGB and Tunable White colors, including inner and outer corners. Maximum design freedom for trade fairs, retail and events. Profile depth: 80 mm. Illumination: 1-, 2- or 3-sided. Application: retail, fair spaces, events. Compatible with: maxima 80, octawall pro.
octalux configurator
Discover the octalux configurator and easily assemble your individual illuminated profiles.
More systems
octawall
A frame system for flexible design of space and brand environment with LED.
maxima
A profile system for impactful brand presentations at fairs and events.
octalumina
A light frame system for standout brand presentations.
octamax
A modular two-storey system for efficient use of space and stability.
octafloor
A load-bearing floor system for indoor and outdoor use.
octarig
Stable ceiling structure for hanging or free-standing setups.
octaclassic
A system of posts and beams for versatile presentation and fair constructions.
family products
family compare
 octalux 40 |  octalux 80 | |
|---|---|---|
| Profile depth | 40 mm | |
| Extrusion cross-section | 40 x 80 mm | |
| Lighting | 1 side (one illuminated surface) | |
| Material | Aluminium with integrated LED strip and transparent cover | aluminium; transparent plastic (cover) |
| LED type | COB (chip-on-board) | COB (chip-on-board) |
| Colours | RGB, 16.8 million colour shades | |
| Control | Remote control (dimming, static colours, dynamic effects) | remote control (dimming, static colours, dynamic effects) |
| Shelves | Bracket L 11 for 8 mm panels, up to 20 kg | |
| Compatibility | octanorm system slot (octawall 40, maxima 40) | |
| Application | Trade fairs / retail spaces / events | |
| Profile edge length | 80 mm | |
| Illuminated sides | 1, 2 or 3 (depending on configuration) | |
| Beam angle | 90° (2 sides) or 180° (3 sides) | |
| Color spectrum | RGB, 16.8 million colours | |
| Color temperature (Tunable White) | 2700 to 6500 K | |
| System groove | 4.3 mm octanorm system slot | |
| Upright profile lengths | 1000, 1500, 2000, 2500, 3000, 3500, 4000, 4500, 5000 mm | |
| Cross-beam lengths | 840, 1840, 2840, 3840, 4840 mm | |
| Construction kits | 2000 x 2000 x 2000 mm, 2000 x 2000 x 2500 mm, 3000 x 3000 x 3000 mm | |
| Shelf load capacity (L 10 / L 11 brackets) | up to 20 kg, 8 mm glass or wood | |
| Power supply | 230 V |
also see
- octalux 40.octalux 40 is the slim Octanorm lighting system for prominent graphics and lightweight light walls; you build it from aluminium profiles, keder and LED technology on the plug & play principle.
- octalux 80.octalux 80 creates powerful lighting accents with built-in LED diodes in RGB or Tunable White. The modular profile system can be configured with single-, double- or triple-sided illumination, opening up entirely new creative possibilities for dynamic brand environments. At the push of a button you conjure up vivid worlds of colour or precisely adjustable white tones for the perfect ambience: from bold statements to elegant lighting concepts for trade fairs, retail spaces and events.
- octalumina 120.With integrated power technology, tool-free assembly and versatile application options, octalumina 120 is ready for every project: from a single accent to a fully illuminated space. Whether free-standing, wall-mounted or suspended, the system is ready to use immediately and connects seamlessly with other octanorm systems. For brand spaces that don't just shine, but make an impression.
- octalumina 40.There are spaces. And there are spaces with impact. A single simple accent like octalumina 40 takes care of that. The system convinces with homogeneous, shadow-free illumination provided by LED diodes on the rear cover. Equally convincing are its decorative and representative sides, which instantly catch the eye. Whether mounted on the wall, suspended from the ceiling or placed as a free-standing corner: simply plug it in. Done. Brilliant.
- octalumina 80.With a profile depth of 80 mm, octalumina 80 combines stability and lightness: the ideal solution for trade fairs, events and retail. Integrated power technology enables true plug & play, while single-sided illumination presents content clearly and with focus. Thanks to compatibility with octawall pro and octalux, countless possibilities open up for modular brand presentations. The result is a system that is as versatile as it is premium and that impresses at every presentation.
- octalumina kubusoctatowers is a free-standing light tower made of aluminium profiles with graphics on all sides. Combined with octalumina kubus, a luminous cube with up to five illuminated sides, it becomes a premium solution for brands that want to stand out in a new dimension.
- octalumina.When light ignites. Octanorm flagship LED system.
- octatowersoctatowers is a free-standing light tower made of octanorm aluminium profiles with graphics on all sides. With its LED lighting, it offers an attractive solution for fairs, exhibitions and events where you want to stand out.
